Up2Stream DAC Board
Upgrade the sound quality of your Up2Stream Board with the famous ESS 9023 Sabre chip found in the Up2Stream DAC Board.
Compatible Products: Up2Stream Mini, Up2Stream Pro
Up2Stream Button Board
This Button board is an external board that contains multiple control buttons including play/pause, volume up, volume down, previous song, next song, standby and switch mode, plus an on board IR receiver, connector for IR Extension Board and 4 mode indicator LED including WiFi, BT, AUX and USB.
It is perfect to use as the control panel for your DIY device.
Compatible Products: Up2Stream Mini, Up2Stream Pro, Up2Stream Amp, Up2Stream Amp 2.1
*Up2Stream Plate Amp 2.1 and Up2Stream HD DAC need to wiring yourself.
Up2Stream SPDIF In Board
Lacking a digital input for your DIY board but want an easy solution?
The SPDIF input board lets you easily add SPDIF input to your device. It contains both an Optical input and Coaxial input jack. With this board, you can connect any device with SPDIF output as a digital audio input source.
Compatible Products: Up2Stream Mini, Up2Stream Pro, Up2Stream Amp, Up2Stream Amp 2.1
Up2Stream SPDIF Out Board
This SPDIF output board can add Digital output to your device, which contains an Optical output and Coaxial output jack. With this board, you can output digital audio data to other devices like a DAC or digital amplifier.
Compatible Products: Up2Stream Mini, Up2Stream Pro,
Up2Stream Amp, Up2Stream Amp 2.1
Up2Stream IR Extension Board
Does the onboard IR receiver not fit your DIY case? Do you need to position it somewhere else?
This IR Extension Board lets you connect an external IR receiver and position it to fit your DIY needs.
*Requires Up2Stream Button Board or Up2Stream Pro, Up2Stream Amp, Up2Stream Plate Amp 2.1, Up2Stream HD DAC need to wiring yourself.
*Up2Stream Mini requires Up2Stream Button board.
Up2Stream Volume Knob Board
Need a volume knob on your DIY project? Then this is perfect for you!
Use this Volume Knob Board to add a volume knob to your device. It is a combined rotary encoder and momentary switch you can use it to turn volume up or down, and for Up2Stream Mini, switch input mode with a press.
Compatible Products: Up2Stream Mini, Up2Stream Pro,
Up2Stream Amp,Up2Cast Amp.
Specification
Up2stream DAC Board
Size
40x38mm
Sample Rate
up to 24bit/192KHz
Audio Output
44.1khz/16bits, CD quality
Dynamic Range
112dB
Interchannel Isolation
100dB
THD+N
0dB FS 0.002%
Power supply
3.3V ± 5%, 23mA 5.0V ± 5%, 31 mA
Pin Content
VC3.3V
GND
LRCK
BCLK
DATA
MCLK
NC
Up2stream Button Board
Size
68x64mm
Up2stream SPDIF In Board
Size
52x24mm
Sample Rate
up to 16bit/176.4MHz
Audio Output
44.1khz/16bits, CD quality
Dynamic Range
112dB
Interchannel Isolation
100dB
THD+N
0dB FS 0.002%
Power supply
3.3V ± 5%, 23mA 5.0V ± 5%, 31 mA
Pin for Up2Stream Mini
SPDIF
MCLK
IIS_DATA
BCLK
LRCK
GND
3V3
Pin for Up2Stream Amp 2.1
SPDIF2
B0
B1
GND
Up2stream SPDIF Out Board
Size
52x24mm
Sample Rate
Sample Rate is same as the connected board
Audio Output
44.1khz/16bits, CD quality
Dynamic Range
112dB
Interchannel Isolation
100dB
THD+N
0dB FS 0.002%
Power supply
3.3V ± 5%, 23mA 5.0V ± 5%, 31 mA
Pin for Up2Stream Mini
SPDIF
MCLK
IIS_DATA
BCLK
LRCK
GND
3V3
Pin for Up2Stream Amp 2.1
SPDIF2
B0
B1
GND
Up2stream Volume Knob Board
Size
22x17mm
Pin Content
GPIO2
GPIO1
KEY
GND
Up2stream IR Extension Board
Size
18x10mm
FAQ
What are these expansion boards for?
They extend your Up2Stream audio module’s functionality, such as volume control, playback buttons, OLED display, and IR remote control.
Is installation difficult? Do I need to solder?
No soldering required. Just plug in the ribbon cable — easy for DIY users.
Some incompatible products can be welded by themselves according to the corresponding interface
Can I use multiple modules at the same time?
Yes, as long as your main board has available ports. For example, you can use the button board, OLED, and IR receiver at the same time.
Are cables included in the package?
Yes, each board comes with its own ribbon cable.
